FCD LMAIM5001-00 DDC-100 Master Station II Installation and Operation Manual 63
Flow Control Division
Limitorque Actuation Systems
14
Emergency Shut Down
Should it be necessary to initiate an Emergency Shut Down of the networked MOVs, this can be accomplished by
accessing the Emergency Shut Down screen from the Main Menu (Figure 14-1).
Figure 14-1: Emergency Shut Down screen
Two options are available: Initiate a shutdown and Clear a shutdown. Once an Emergency Shut Down has completed and
is no longer necessary, the Emergency Shut Down state is cleared by pressing the Clear button.
When an Emergency Shut Down is Initiated, the Emergency Shut Down in Progress screen will be displayed
(Figure 14-2).
Figure 14-2: Emergency Shut Down in Progress screen
Emergency Shut Down In Progress
The Emergency Shut Down Procedure
has been initiated.
Main Menu
Procedure Complete
Emergency Shut Down ACTIVE
Pressing the red button will initiate
an Emergency Shut Down procedure
for the Network.
Once Initiated, the Emergency Shut
Down Procedure cannot be revoked.
Clear
Emergency
Shut Down
Initiate
Emergency
Shut Down
Cancel
