FCD LMAIM5001-00 DDC-100 Master Station II Installation and Operation Manual 7
Flow Control Division
Limitorque Actuation Systems
Figure 1-3: The Login Help screen
Note: The keys are outlined in red on this screen.
1.4 Main Menu
Figure 1-4: The Main Menu screen
From here, the user is restricted by his role. Each button represents a separate logical region of the
Master Station:
Configure: configure the Master Station and the Network.
Network Status: view the Network from a high level to detect communication errors.
Hot Standby: change over of CPU and configure CPU startup status.
View MOV Status: view the detailed status of each MOV.
Logger: activate logging, either for the network or for data analysis. This data will stream out of the
printer port.
Control MOV: control a MOV’s position.
Emergency Shut Down: initiate or clear an emergency shutdown of the network.
Main Menu ACTIVE
Emergency
Shut Down
Control MOV
Exit
Logger
Configure
Hot Standby View MOV Status
Network Status
7 8 9
6 5 4
1 2 3
0
DEL CLR
E
N
T
<< Back
Login Help: Enter the Reset Password
****
