FCD LMAIM5001-00 DDC-100 Master Station II Installation and Operation Manual 33
Flow Control Division
Limitorque Actuation Systems
Figure 7-4: RTS ON Delay screen
Press Back after editing values.
Figure 7-5: RTS OFF Delay screen
Press Back after editing values.
Touching “Next >>” on the DCS Port Configuration screen will take the user to the next DCS Data Table
Configuration screen.
7.2 Data Table Configuration
The Master Station data table is configurable for the Modbus Function codes 01, 05, 03, 05/15, 06/16.
The Modbus function codes 02 and 04 have a fixed data table and do not permit user alteration
(Figure 7-6).
RTS Off Delay
Current Value:
0
1-65535
Valid Range:
Time delay
(1 ms each incr.)
after the last
char. transmit
and before RTS
is dropped.
0
<< Back
7 8 9
6 5 4
1 2 3
0 . CLR
DEL
-
E
N
T
RTS On Delay
Current Value:
0
1-65535
Valid Range:
Time delay
(1 ms incr.)
between asserting
RTS and the
transmission of
data.
0
<< Back
7 8 9
6 5 4
1 2 3
0 . CLR
DEL
-
E
N
T
