LBC-4000 L-Band Up/Down Converter System Revision 4
Introduction MN/LBC4000.IOM
1–5
1.4 Summary of Specifications
1.4.1 Physical & Environmental
Weight 25 lbs. (11.34 kg) Maximum
Dimensions (excluding connectors)
19”W x 1.75”H (1RU) x 22”D (482.6 x 44.45 x 559.0 mm)
(See Figure 1-3)
Temperature
Operating 32º to 122ºF (0º to 50ºC)
Non-operating (Storage) -58º to 160ºF (-50º to 71ºC)
Operational Altitude 10,000 ft above sea level
Operational Humidity 5 to 95% non-condensing
Shock Normal commercial shipping and handling
1.4.2 Prime Power
Voltage 90 to 260 VAC
Frequency 47 to 63 Hz
Dissipation 35 Watts total, two up/downconverters
1.4.3 External Reference
Input Frequency
5 or 10 MHz, Auto detect
BNC Female connector
Input Level ±5 dBm
Input Impedance 50Ω
1.4.4 Monitor & Control
Serial M&C Interface
TIA/EIA-232, TIA/EIA-485, 4-wire
DB-9F connector
Alarm Form C, DB-9F connector
Redundant Switch Connections SMA Female
