MBT-4000 Multi-Band Transceiver System Revision 4
Remote Control MN/MBT4000.IOM
A–13
Parameter
Type
Command
(Instruction
Code and
qualifier)
Valid on
MBT,
BDC, or
BUC
Arguments
for Command
or Response
to Query
Description of Arguments
(Note that all arguments are ASCII numeric codes – i.e.,
ASCII codes between 48 and 57)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code and
qualifier)
Response to
Query
(Target to
Controller)
Monitor LNA
Current N/A MBT s_xxx.x,
s=1 byte,
value of 1, 2
1=LNA A
2=LNA B
xxx.x=5 bytes,
numeric Query only.
Returns LNA Current Source Level in mA.
Example:
<0001/LCM?2
>0001/LCM=2_045.3{cr}{lf}
LCM= (message ok)
LCM? (received ok,
but invalid arguments
found)
LCM! (command not
accepted by BUC or
BDC sub-units) LCM?s
s=1 byte,
value of 1, 2
LCM=s_xxx.x
LNA Current
Source LCS=sx MBT s=1 byte,
value of 1, 2
1=LNA A
2=LNA B
x=1 byte,
value of 0, 1
0 = Disable
1 = Enable Command or Query.
LNA Current Source Enable, where:
Source Enable
1=LNA A (Aux Comm 1)
0 = Disabled2=LNA B 2=LNB B
(Aux Comm 2) 1 = Enabled
Example: LCS=10
LCS= (message ok)
LCS? (received ok,
but invalid arguments
found)
LCS* (message ok,
but not permitted in
current mode)
LCS! (command not
accepted by BUC or
BDC sub-units) LCS?s
s=1 byte,
value of 1, 2
LCS=sx
(same format as
command
arguments)
LNA Current
Source LCS=x BDC x=1 byte,
value of 0, 1
0 = Disable
1 = Enable
Command or Query.
LNA Current Source Enable, where:
0 = Disabled
1 = Enabled
Example: LCS=0
LCS= (message ok)
LCS? (received ok,
but invalid arguments
found)
LCS* (message ok,
but not permitted in
current mode)
LCS! (command not
accepted by BUC
sub-units) LCS?
LCS=x
(same format as
command
arguments)
LNA Current
Window LCW=xx BDC xx=2 bytes,
numeric
Command or Query.
This command allows the user to set the alarm window in
± % of
the calibrated LNA Current. Valid inputs are 20 to 50 in
increments of 1%. In addition, setting the value to 99 disables
the alarm function.
Default is Disabled.
Example: LCW=30, set alarm window for LNA A (Aux Comm 1)
to
± 30%.
LCW= (message ok)
LCW? (received ok,
but invalid arguments
found)
LCW* (message ok,
but not permitted in
current mode)
LCW! (command not
accepted by BDC
sub-units) LCW? LCW=xx
(same format as
command
arguments)
