MBT-4000 Multi-Band Transceiver System Revision 4
Remote Control MN/MBT4000.IOM
A–7
Parameter
Type
Command
(Instruction
Code and
qualifier)
Valid on
MBT,
BDC, or
BUC
Arguments
for Command
or Response
to Query
Description of Arguments
(Note that all arguments are ASCII numeric codes – i.e.,
ASCII codes between 48 and 57)
Response to
Command
(Target to
Controller)
Query
(Instruction
Code and
qualifier)
Response to
Query
(Target to
Controller)
Automatic
Fault
Recovery
State AFR=x All 1 byte, value
of 0, 1 Command or Query.
Enable Automatic Fault Recovery on a BXC, where:
0=Disabled
1=Enabled
Example: AFR=1 AFR=(message OK)
AFR? (received OK,
but invalid arguments
found)
AFR*(message OK,
but not permitted in
current mode) AFR? AFR=x
(same format as
command
arguments)
Attenuation ATT=xx.xx BDC
BUC
5 bytes,
numeric Command or Query.
Valid attenuation level, in dB, at 0.25dB step size as factory
default.
Example: ATT=08.25 ATT=(message OK)
ATT? (received OK,
but invalid arguments
found)
ATT*(message OK,
but not permitted in
current mode)
ATT! (Command not
accepted by MBT-
4000 base unit. It
must be addressed
to BUC or BDC sub-
units)
Clear All
Stored Alarms CAA= All None Command only.
Instructs the slave to clear all Stored Events.
This command takes no arguments.
CAA=(message OK) N/A N/A
Concise AUX
COMM I/O N/A MBT n=Slot
1=AUX
COMM 1
2=AUX
COMM 2 Query only.
Used to Query the Concise AUX COMM I/O of the MBT-4000
base unit, where: n=1 (AUX COMM 1) or 2 (AUX COMM 2)
Example: <0001/CAI?n{cr}
>0001?CAI=nabcd{cr}{lf}
Where:
n=1 or 2 (AUX COMM)
a=12V (0=Off, 1=On)
b=IOA (O=logic low [voltage input < 0.5],
1=logic high [voltage input > 2.7 vdc)
c=IOB (O=logic low [voltage input < 0.5],
1=logic high [voltage input >2.7 vdc]
d=Reserved (Always zero)
CAI=(message OK)
CAI? (received OK,
but invalid arguments
found)
CAI*(message OK,
but not permitted in
current mode)
CAI?n CAI=nabcd
(see description
for details of
arguments)
