Users Manual SS Finisher Assembly Drawings Mechanical •••• 57
Stacker Parts List
Item Part # Description Qty
1 928002 Platform shim 1
2 990103 10-32 Hex nut 6
3 928012 Spring 3
4 158110 Base platform shim 1
5 428016 Guard back stacker 1
6 990416 ¼-20 x ½” Flat head screw 2
7 990469 .031 Nylon washer 5
8 428019 Back guide mount assembly 1
9 990089 10-32 x ¼” Button head screw 4
10 158112 Stop, Stacker 1
11 990468 10-32 x 1” Binding head screw 2
12 428022 Stacker assembly, Outer 1
13 928008 Lock, Stacker side 2
14 990084 10-32 x 1” Cap screw 1
15 201455 Spring 1
Can be ordered as an assembly
428093 2” stacker assembly
