Users Manual SS Finisher Operation •••• 13
Power
"Power" on pilot light indicates when the power supply is on. This only indicates
that the power supply is connected to the line power. Ultrasonic energy is only
generated during the actual cut cycle. This is indicated by the green light next to
the US_TIME control.
Connecting the Ultrasonic Power Supply
Line Cord
Plug the line cord into the mating receptacle on the back of the power supply and
secure it with the metal bail. Plug the other end of the line cord into the line
(mains) receptacle.
Sonic Stack Cable
The Sonic Stack Cable plugs into the mating connector on the rear of the Power
Supply. Insert the plug firmly into the socket until it is fully seated.
Power Supply Control Cable
The Power Supply Control Cable plugs into the 37-pin connector on the rear of
the Power Supply. Plug in the cable and secure with the retaining screws.
NOTE: The Ultrasonic Power Supply does not have a power switch. It is
on all the time. Ultrasonic energy is only generated during the cut cycle.
