Avery Dennison SS Finisher - Manual (Page 55)

Users Manual SS Finisher Assembly Drawings Mechanical •••• 55
Conveyor Parts List
Item Part # Description Qty Item Part # Description Qty
1 428103 Assembly, Conveyor bottom 1 22 999082 Bushing, Iglide 2
2 551146A Motor, Ink save, Alt 1 23 428047 Roller, Lap drop 1
3 224067 Bracket, Motor mount ns 1 24 428049 Bracket, Conveyor 2
4 422029 Shaft, Drive roller 1 25 428062 Bracket, Stripper 1
5 428059 Conveyor, Main frame 1 26 428056 Shaft, Conveyor idler 1
6 428041 Support, Outboard 1 27 428052 Bar, Conveyor stripper 1
7 428031 Spacer, Conveyor plate 2 28 206042 Thumb screw knob 1
8 990125 1/4-20 x 1 1/2" Cap screw 2 29 990424 4-40 x 3/8" Cap screw 2
9 428035 Frame, Conveyor side 2 30 990056 8-32 x 1/2 Flat hd cap screw 4
10 428048 Roller, Conveyor 6 33 990066 8-32 x 1/4" Button hd cap screw 2
11 422034 Bearing, 1/4 x .29 Spacer 1 34 990262 Snap ring, 1/4" 2
12 422033 Bearing, 1/4 x .15 Spacer 1 35 990167 Washer, 1/4" Flat 2
13 422026 Gear, 72T / 36T Combo 2 36 990145 Washer, 1/4 Lock 2
14 422032 Gear, 36T Reworked 1 37 990242 Roll pin, 1/8 x 3/4" 2
15 422028 Bracket, Motor plate 1 38 990247 Roll pin, 1/8 x 1/2" 1
16 991068 Dowel pin, 1/4 x 7/8" 2 39 990057 8-32 x 1/8" Set screw 2
17 428061 Pulley, Drive 2 40 990081 Hexagon socket head cap screw 13
18 422030 Guard, Gear 1 41 999081 Bushing, Iglide 12
19 990015 6-32 x 1/4" Socket hd cap screw 2 991028 "O" Ring drive belt (not shown) 4
20 422031 Gear, 30T Reworked 1
