Users Manual SS Finisher Appendix C •••• 36
Labels Rate Chart
Machine Speed in Inches per Second
LABEL LENGTH 2 IPS 3 IPS 4 IPS 4.5 IPS 5 IPS 6 IPS 7 IPS
1.0” (25mm) 122 FALSE FALSE FALSE FALSE FALSE FALSE
1.2” (30mm) 102 FALSE FALSE FALSE FALSE FALSE FALSE
1.4” (35mm) 87 131 FALSE FALSE FALSE FALSE FALSE
1.6” (40mm) 76 114 FALSE FALSE FALSE FALSE FALSE
1.8” (45mm) 68 102 FALSE FALSE FALSE FALSE FALSE
2.0” (50mm) 61 91 122 FALSE FALSE FALSE FALSE
2.2” (55mm) 55 83 111 125 FALSE FALSE FALSE
2.4” (60mm) 51 76 102 114 FALSE FALSE FALSE
2.6” (65mm) 47 70 94 106 117 FALSE FALSE
2.8” (70mm) 44 65 87 98 109 FALSE FALSE
3.0” (75mm) 41 61 81 91 102 FALSE FALSE
3.2” (80mm) 38 57 76 86 95 114 FALSE
3.4” (85mm) 36 54 72 81 90 108 FALSE
3.5” (90mm) 34 51 68 76 85 102 FALSE
3.7” (95mm) 32 48 64 72 80 96 FALSE
4.0” (100mm) 30 46 61 69 76 91 107
4.1” (105mm) 29 44 58 65 73 87 102
4.3” (110mm) 28 42 55 62 69 83 97
4.5” (115mm) 27 40 53 60 66 80 93
4.7” (120mm) 25 38 51 57 64 76 89
5.0” (125mm) 24 37 49 55 61 73 85
5.1” (130mm) 23 35 47 53 59 70 82
How to Use Chart:
• Locate the desired label length or next highest length shown in the left hand
column.
• Move across the top of the page to the desired speed
• Move down the column and match the label length selected
• This is the estimated labels per minute rate the SS Finisher will produce.
All marginal size labels must be tested with the desired format.
• If the speed selected is listed as “False” move to the next slower speed
available.
• Any speed between the “False” rate and the next highest allowed speed
MAY run but must be tested on the desired format.
