Users Manual Model 656/636 Assembly Drawings • •• • 101B
Knife Parts List
Item Part # Description Qty Item Part # Description Qty
1 357091 Bracket, Inner knife assembly 1 17* 3 990019 6-32 x 1/4 Button head screw 1
2 355018 Support, Knife / Drive / Print 1 18* 1,2 357003 Mount, Solenoid 1
3 357092 Bracket, Outer knife ass’y 1 19* 1,2 357020 Actuator, Knife 1
4 197308 Adjuster, Knife 1 20 990082 10-32 x 5/8 Cap screw 4
5* 3 357094 Ass’y, Ground rotary (6x6) 1 21* 1 990016 6-32 x 3/8 Cap screw 4
6* 2 197311 Cam, Knife homing 1 22 990120 1/4-20 x 1/2 Cap screw 2
7 990055 8-32 x 3/8 Flat head screw 1 23* 1,2 990325 Snap ring, 3/16 "e" ring 1
8 989978 Washer, #8 Star 1 24* 3 197319 Torsion spring, Right 1
9 990065 8-32 x 3/8 Button head screw 1 25* 3 357029 Torsion spring light, Back 1
10* 2 991067 8-32 x 5/16 Knurled cup point 2 26* 1,2 351123 Knife solenoid, Harnessed 1
11* 3 357093 Knife, Stationary ass’y 1 27* 1,2 197317 Compression spring, Solenoid 1
12 517099 Assembly, Knife motor, 600 rpm 1 28* 1,2 357089 Ass’y, Cam spring 1
13 990102 Washer, #10 SAE 2
14 990123 1/4-20 x 1 Cap screw 2 * 1 357096 6x6 Solenoid kit
15* 2 357019 Clutch, 6 roller, Sq drive 1 * 2 357097K 6x6 Knife Solenoid / Clutch kit
16 357016 Standoff, Solenoid arm 1 * 3* 2 357098K 6x6 Solenoid / Clutch / Blade kit
921178 Finger Guard (install when knife is
removed for safety - NS)
1
357095 Oiler Assembly (NS) 1
357090K Knife Module Assembly (NS) 1
