Software Installation and Configuration
System Management Interface Based on HPI-B (Centellis CO31kX/4100/2000/4410) User’s Guide 27
Table 2-5 Plugin Specific Parameters
Tag Description Allowed values Default in Config. file Built-in Default
entity_root
Root entity value
{description> ,
<0…N>} [{ADVANCEDTCA_CHASSIS,
0}]
- Any entity's path would
be starting with the above
string
Can be evaluated
in 2 ways
1.Uses shelf
address as the
integer
2.If step 1 fails,
then uses 0
name
Interface name for ipmi
connection
"smi | lan" [smi]
– connection over SMI
interface
lan
– connection over LAN
"smi"
- if HPI is
running on shelf
manager
"lan"
- if HPI is
running on
management
controllers other
than shelf
manager.
DomainTag
Tag for the domain Any valid tag [ATCA Shelf]
ATCA Shelf
sel_filename
System event log file
name
Any valid file name
[/var/lib/bbs-
hpib/shelf_sel.db]
Commented out by default
NA
max_number_of_sel_entrie
s
Maximum number of
SEL entries
<0…N> [100]
Commented out by default
NA
IpmiConnectionTimeout
IPMI Connection
timeout
<0…N> msecs [1500] -
1500 milliseconds NA
AtcaConnectionTimeout IPMI driver/smi timeout <0…N> msecs [1500] - 1500 milliseconds 1000
MaxOutstanding
Maximum number of
outstanding IPMI
commands
<0…N> [10]
- 10 commands by
default. After this max is
reached, any other request is
awaited.
0
PtpEKeyingMode
E-keying mode
<0,1,2> [2]
– Full e-keying. To do
the e-key on both local
and remote ports
1
– Simple e-keying. To do
the e-key on only local ports
0
– Disable the e-keying
Full e-
keying
ResourcePowerOffTimeout
A timeout after which
the resource FRU Power
State will be set to initial
state. This timer is
started soon after
executing the Power
Off/Power
Cycle/hotswap
operations on the
resource.
<0…N> [60000]
- 60000 ms
60000
