Remote Interface Protocol and Package Mode
CURR1:PROTECTION? ==>
return
over current for channel 1
CURR:PROTECTION? ==>
return
over current for channel 1
OISET2? ==>
return
over current for channel 2
How to enable or disable over voltage protection (OVP):
SOUR:VOLTAGE3:PROT:TRIG ON
==>
enable OVP for channel 3.
SOURCE:VOLT1:PROT:TRIG OFF
==>
disable OVP for channel 1.
SOUR:VOLT2:PROTECTION:TRIG OFF ==>
disable OVP for channel 2.
VOLTAGE3:PROT:TRIG ON
==>
enable OVP for channel 3.
VOLT2:PROT:TRIGGER ON
==>
enable OVP for channel 2.
VOLT1:PROTECTION:TRIG OFF
==>
disable OVP for channel 1.
VOLT:PROTECTION:TRIG OFF
==>
disable OVP for channel 1.
OVP2 ON
==>
enable OVP for channel 2.
OVP3 OFF
==>
disable OVP for channel 3.
How to enable or disable over current protection (OCP):
SOUR:CURRENT3:PROT:TRIG ON
==>
enable OCP for channel 3.
SOURCE:CURR1:PROT:TRIG OFF
==>
disable OCP for channel 1.
SOUR:CURR2:PROTECTION:TRIG OFF ==>
disable OCP for channel 2.
CURRENT3:PROT:TRIG ON
==>
enable OCP for channel 3.
CURR2:PROT:TRIGGER ON
==>
enable OCP for channel 2.
CURR1:PROTECTION:TRIG OFF
==>
disable OCP for channel 1.
CURR:PROTECTION:TRIG OFF
==>
disable OCP for channel 1.
OCP2 ON
==>
enable OCP for channel 2.
OCP3 OFF
==>
disable OCP for channel 3.
How to set up a program (example):
PROG 10
==> define program 10
PROG:ISET1 1
==> set max. output current of 1A for ch1
PROG:ISET2 1
==> set max. output current of 1A for ch2
PROG:ISET3 1
==> set max. output current of 1A for ch3
PROG:VSET1 1
==> set output voltage of 1V for ch1
PROG:VSET2 1
==> set output voltage of 1V for ch2
PROG:VSET3 1
==> set output voltage of 1V for ch3
PROG:FAST 4
==> output above setting for 4 ms
