Channel Width: The selected bandwidth from “BASIC WIRELESS” is shown. Other
options include HT5, HT10 and HT20. The larger the bandwidth the lower number of
channel options available to use.
Local AP Statistics: The transmitted and received data packets over the RF connection
are recorded and viewable here. Any error will also be captured. The refresh button will
update the transmission statistics.
Local AP Errors: Any additional error and/or collision in the wireless traffic when a host
is connected to a client or group of clients will be captured and displayed in this section
helping to identify the loss of data over the wireless link.
3.2.1.6
Status: More Status (Pull Down Menu)
The pull down menu for More Status is a quick link tool to various services diagnostic
tools. Each of the following is also covered under section 3.2.2 below.
Ping Utility:
Use to ping from within the Mesh2HT node interface.
ARP Table:
View the ARP Table. The ARP table is view only.
Bridge Table:
Select to view the wireless bridge table. Details described under section 3.2.2.4.
