DeviceNet Remote I/O Communication Module RTU-DNET
DVP-PLC Application Manual 30
Register in
DVPDNET-SL
Devices in extension module
D6287H High byte of control word in RTU-DNET
D6287L
RTU-DNET
control word Low byte of control word in RTU-DNET
D6288H High byte of CH1 on DVP-02DA
D6288L Low byte of CH1 on DVP-02DA
D6289H High byte of CH2 on DVP-02DA
D6289L
Special
module
Low byte of CH2 on DVP-02DA
D6290H Slim DI/DO Y0 ~ Y7 on DVP-16SP
(2) RTU-DNET → DVPDNET-SL
Register in
DVPDNET-SL
Devices in extension module
D6037H High byte of status word in RTU-DNET
D6037L
RTU-DNET
status word Low byte of status word in RTU-DNET
D6038H High byte of CH1 on DVP-04AD
D6038L Low byte of CH1 on DVP-04AD
D6039H High byte of CH2 on DVP-04AD
D6039L Low byte of CH2 on DVP-04AD
D6040H High byte of CH3 on DVP-04AD
D6040L Low byte of CH3 on DVP-04AD
D6041H High byte of CH4 on DVP-04AD
D6041L Low byte of CH4 on DVP-04AD
D6042H High byte of CH1 on DVP-04TC
D6042L Low byte of CH1 on DVP-04TC
D6043H High byte of CH2 on DVP-04TC
D6043L Low byte of CH2 on DVP-04TC
D6044H High byte of CH3 on DVP-04TC
D6044L Low byte of CH3 on DVP-04TC
D6045H High byte of CH4 on DVP-04TC
D6045L Low byte of CH4 on DVP-04TC
D6046H High byte of CH1 on DVP-04PT
D6046L Low byte of CH1 on DVP-04PT
D6047H High byte of CH2 on DVP-04PT
D6047L Low byte of CH2 on DVP-04PT
D6048H High byte of CH3 on DVP-04PT
D6048L Low byte of CH3 on DVP-04PT
D6049H High byte of CH4 on DVP-04PT
D6049L
Special
module
Low byte of CH4 on DVP-04PT
D6050H X0 ~ X7 on DVP-08ST
D6050L
Slim DI/DO
X0 ~ X7 on DVP-16SP
