DeviceNet Remote I/O Communication Module RTU-DNET
DVP-PLC Application Manual 11
Attribute
ID
Access
rule
Name Range Default Explanation
8 Get Status word 0~255 N/A
Displaying the status of RTU-DNET.
See 4.3 for more details.
9 Get/Set Control word N/A N/A
For setting up the mode of RTU-DNET,
e.g. “H8000” for STOP mode and
“H8001” for RUN mode. See 4.3 for
more details.
10 Get/Set
Diagnostic
interval time
1 ~ 65
secs
5 secs
The interval when RTU-DNET
executes diagnosis.
11 Get/Set
Special
module offline
treatment
0 ~ 2 1
How RTU-DNET will react when the
special module connected to it is
offline.
0: Ignored
1: Alarm
2: Stop DeviceNet IO
12 Get/Set
Special
module error
treatment
0 ~ 2 1
How RTU-DNET will react when it
detects errors.
0: Ignored
1: Alarm
2: Stop DeviceNet IO
13 Get/Set
RTU-DNET
configuration
validation
N/A 0
Validating the configuration of
RTU-DNET when set to “11”.
14 Get/Set
Reset
RTU-DNET
N/A 0
Resetting RTU-DNET when set to”10”.
After it, the parameter will change to
“0” automatically.
„ Class 0x9B – Extension module setup parameter object
Class attribute
Attribute ID Access rule Name Data type
1 Get Revision UINT
Instance 1 ~ 8 (parameters for the 1st ~ 8th special modules)
Attribute
ID
Access
rule
Name Range Default Explanation
1 Get Model name N/A N/A Model code for the special module
2 Get
Length of
input data
N/A N/A
The sum of the input data length of
special modules connected.
Unit: word
3 Get
Length of
output data
N/A N/A
The sum of the output data length of
special modules connected.
Unit: word
0 Special module online
b0
1 Special module offline
0 Special module normal
b1
1 Special module in error
4 Get Status 0 ~ 63 N/A
b2 0
Special module and
configuration consistent
