4-11
4.2 Configuration in a browser
4 Configure PSS 4000 Diag Control
4.2.3 Properties for split window display (Split Window (2/2) tab)
Properties for split window display (Split Window (2/2) tab) 4- PSS4000 Diag Control Properties Split Window 2_Diagnosemeldungen
Display of diagnostic messages
Properties for show/hide, plus column layout, e.g.
NAME="ListCol1" VALUE="Timestamp">:
 ListCol N (N columns from 1 to 11)
– Values:
– "Timestamp"
– "PriorityNo"
– "DID"
– "Scope"
– "Description"
– "Location.Device"
– "Location.EquipmentID"
– "Location.Description"
– "Location.Address"
– "Priority"
– "ParameterList"
– "Deactivated" = Invisible column
Properties for assigning column widths, e.g.
NAME="ListColWidth1" VALUE="80">
 ListColWidth N (N columns from 1 to 11)
– Values:
– Column width in pixels
PSS4000 Diag Control Properties Split Window 2 Abhilfe
INFORMATION
Please note the following with properties:
– Always state a value in all the columns under "ListCol N or in
none of them.
– Each column should be assigned a unique value
– If you don't wish to use every value, the remaining columns
should be assigned the value "Deactivated" (see example).
– If the "ListCol N " properties are stated, then all the "ListCol-
Width N " properties must also be stated.
