Parts list, 2010 mustang gt, h.o. cont’d – Vortech 2005-2010 Ford 4.6L 3v Mustang GT User Manual
Page 22
P/N: 4FU020-010 v6.2, 06-08-10
©2010 Vortech Engineering, LLC
All Rights Reserved, Intl. Corp. Secured
xxii
2010 Mustang GT, H.O. cont’d
Part No. 4FU218-108L/108L
7U038-150
HOSE, 3/4"X150° MOLDED HOSE
1
7U100-055
TIE WRAP, 7.5" NYLON
6
7U375-054
3/4" VINYL CAP
1
8D001-001
STD COMPRESS BYPASS VALVE
1
8F001-403
PUMP, WATER, BOSCH
1
8N010-160
SURGE TANK BRKT, MUST GT
1
8N010-220 MTG BRKT, 05-07 MUST BOSCH PMP
1
8N055-050
PLASTIC CAP, SURGE TANK
1
8N056-061 SURGE TANK INTEGRA GSR MODIFIE
1
8N106-135
WATER CLR ASY, MUST GEN.II
1
8N006-020
WATER COOLR, FLDYN DUAL PASS
1
8N010-171 BRACKET, DRVR SIDE CLR MNT,PLT
1
8N010-173
BRACKET, PASS SIDE CLR MNT
1
2A017-036
SPACER,PLT.BRG.HSG.,0.186"
4
7C080-030
M8 X 1.25 X 30 HXHD CL10.9
6
7F008-020
NUT, M8 X 1.25
6
7J312-000
5/16 FLAT WASHER-SAE
12
7A250-051
1/4-20 X .50 HHCS ZINC PLTD
4
7J250-001
1/4 WASHER, SAE, PLTD
4
8N155-082
COOLANT RES RELOC, 07-08 MUST 1
4FU010-061 BRKT B, COOL RES RELOC MUST
1
4FU010-091
BRKT, COOL RES RELOC, 07 GT
1
7A250-051
1/4-20 X .50 HHCS ZINC PLTD
4
7A250-074
1/4-20 X .75 HHCS PLTD
3
7F250-021
1/4-20 NYLOCK NUT ZINC PLATED
3
7J006-093
6MM WASHER, PLATED
10
7P100-076
HOSE REDUCER, 1"->3/4" PLSTC
1
7P250-045
1/4 MALE NPT X 3/8 MALE BARB
1
7P375-050
3/8" HOSE UNION, BRASS
1
7R002-010
#10 HOSE CLAMP
2
7R004-002
STEPLESS CLAMP, 17.0-70
3
7U030-056
3/8 PCV/VAC RUBBER HOSE
2.5
7U038-000
3/4" HEATER HOSE
1.83
8N055-080
TANK, RAD OVERFLOW, MUST
1
8N104-127
SUPRT PCS, 2010 MUST GT CLR
1
4FE014-010
RADIATOR PIPE-STAINLESS
1
5W001-009
16-14GA MALE SLIDE INSULATED
1
5W001-011
16-14 GA RING TERM .26" HOLE
1
5W001-015
FUSE, BLADE TYPE 20 AMP
1
5W001-022
T-TAP CONN,14-16 AWG
1
5W001-032
1/4" PLASTIC WIRE LOOM
60IN
5W001-050 HARNESS, FUEL INJ PLUG W/WIRES
1
5W001-071
FUSE HOLDER,16GA WIRE
1
5W018-010
18GA STRD WIRE RED
5FT
7A250-050
1/4-20 X .50 SHCS GR8 ZINC PLT
3
7A250-051
1/4-20 X .50 HHCS GR5 ZINC PLT
2
7A250-074
1/4-20 X .75 HHCS PLTD
2
7F250-020
1/4-20 HEX NUT
2
7J006-093
6MM WASHER, PLATED
5
7J250-001
1/4 WASHER, SAE, PLTD
4
7P156-082
5/32 TEE
1
7P218-156
VAC TEE, 7/32,7/32,5/32
1
7P375-075
3/4" HOSE BARB UNION, BRASS
5
7P500-026
1/2NPT X 3/4 BARB 90° BRASS
2
7P500-078
1/2NPT X 3/4 HOSE FIT STRT
2
7R002-016
#16 SAE TYPE F SS HOSE CLAMP
4
7R002-024
#24 SAE TYPE F SS HOSE CLAMP
2
7R002-044
#44 SAE TYPE F SS HOSE CLAMP
2
7R002-072
#72 SAE TYPE F SS HOSE CLAMP
2
7R003-016
ADEL CLAMP, 1.0"
1
7R003-028
ADEL CLAMP, 2-3/8" .26 HOLE
2
7R007-001
NYLON RATCHET CLAMP 1-1/8"
18
7S275-055
ELBOW, °2.75 X 55° SILICONE
1
IMPORTANT: Before beginning installation, verify that all parts are included in the kit. Report any shortages or dam-
aged parts immediately.
ENGINEERING, LLC
PARTS LIST
®
7S450-200
SLEEVE, 4 1/2 X 2, BLUE
1
7U030-046
5/32" VACUUM LINE
5FT
7U030-065
HOSE, 3/4 X 90° RUBBER, SHORT
1
7U034-016
1" GS HEATER HOSE
1FT
7U034-016
1" GS HEATER HOSE
1.25FT
7U038-000
3/4" HEATER HOSE
12FT
7U038-012
HOSE, 3/4 DIA 90°, 4 X 12 LEGS
1
7U038-020
HOSE, 3/4 DIA 'S' MOLDED RUBBE
1
7U038-150
HOSE, 3/4 D X 150° MOLDED HOSE
1
7U100-055
TIE WRAP, 7.5" NYLON
6
7U375-054
3/4" VINYL CAP
1
8D001-001
STD COMPRESS BYPASS VALVE
1
8F001-403
PUMP, WATER, BOSCH
1
8N010-160
SURGE TANK BRKT, 05 MUST GT
1
8N055-050
PLASTIC CAP, SURGE TANK
1
8N056-061 SURGE TANK INTEGRA GSR MODIFIE
1
8N010-340 MTG BRKT 2010 MUST GT BOSCH PM
1
7U133-060
3/4" X 90° HOSE 5"X3.5" LEGS
1
7A250-376
1/4-20 X 3/4 SHOULDER SHCS NYL
2
7F250-021
1/4-20 NYLOCK NUT ZINC PLATED
2
7C010-075
M8 X 1.25 X75 STUD
4
2A017-753-02
SPACER,.750 OD X .880 LONG
4
7J008-001
5/16" FENDER WASHERS
4
7F008-023
NUT, M8 X 1.25 NYLOCK NUT
8
7A250-376
1/4-20 X 3/4 SHOULDER SHCS NYL
2
7F250-021
1/4-20 NYLOCK NUT ZINC PLATED
2
PART NO. DESCRIPTION QTY. PART NUMBER DESCRIPTION QTY.
