Chapter 4: Wireless Tab
airOS
™
v5.5.4 User Guide
Ubiquiti Networks, Inc.
WPA or WPA2
The configuration options are the same for all of the WPA
and WPA2 options. WPA2-AES is the strongest security
method. If all of the wireless devices on your network
support this option, we recommend that you select it.
WPA Authentication
Specify one of the following WPA
key selection methods:
•
PSK
Pre-shared Key method (selected by default).
•
EAP
EAP (Extensible Authentication Protocol)
IEEE 802.1x authentication method. This method is
commonly used in enterprise networks.
PSK
WPA Preshared Key
Specify a passphrase. The preshared
key is an alpha-numeric password between 8 and 63
characters long.
Show
Check the box if you want to view the characters of
the WEP Preshared Key.
Mac ACL
This option enables the MAC address Access
Control List. For details, refer to “MAC ACL” on page 25.
EAP
EAP ‑ Station Mode
The options below apply in Station mode only.
EAP‑TTLS / EAP‑PEAP
Select the authentication protocol
used by your AP.
MSCHAPV2
Inner authentication protocol.
WPA Anonymous Identity
Enter the identification
credential used by the supplicant for EAP authentication
in unencrypted form.
WPA User Name
Enter the identification credential used
by the supplicant for EAP authentication.
WPA User Password
Enter the password credential used
by the supplicant for EAP authentication.
Show
Check the box if you want to view the characters of
the WPA User Password.
EAP‑ Access Point Mode
The options below apply in Access Point or AP‑Repeater
mode only.
Auth Server IP/Port
In the first field, enter the IP
address of the RADIUS authentication server. RADIUS is a
networking protocol providing centralized Authentication,
Authorization, and Accounting (AAA) management for
computers to connect to and use a network service.
In the second field, enter the UDP port of the RADIUS
authentication server. The most commonly used port is
1812, but this may vary depending on the RADIUS server
you are using.
Auth Server Secret
Enter the password. A shared
secret is a case-sensitive text string used to validate
communication between two RADIUS devices.
Show
Check the box if you want to view the characters of
the Auth Server Secret.
Accounting Server
If you are using a separate accounting
server, check the Enable box.
Acct Server IP/Port
If the Accounting Server is enabled,
enter the IP address of the accounting server.
In the second field, enter the UDP port of the RADIUS
accounting server. The most commonly used port is 1813,
but this may vary depending on the RADIUS server you
are using.
Acct Server Secret
If the Accounting Server is enabled,
enter the password. A shared secret is a case-sensitive
text string used to validate communication between two
RADIUS devices.
Show
Check the box if you want to view the characters of
the Acct Server Secret.
Mac ACL
This option enables the MAC address Access
Control List. For details, refer to “MAC ACL” on page 25.
