B-8

Point IO™ 2/4 Channel Analog HART Module

User’s Manual Pub. 0300257-01 Rev. A

Command

Data in Command

Data in Reply

Contained in

No.

Function

Byte

Data

Type

(6)

Byte

Data

Type

(6)

Input

Tag

CIP
MSG

additional
damping
value

additional damping
value (seconds)

65

Write
analog
output
range
value

0

1

2…5

6…9

Analog output
number code
Analog output
range units code
Analog output
upper-range value
Analog output
lower-range value





(F)

(F)

66

Enter/exit
Fixed
Analog
Output
mode

0
1
2…6

Analog output
number code
Analog output units
code Analog output

level

(5)

(F)

67

Trim
analog
output zero

0

1

2…6

Analog output
number code
Analog output units
code
Externally
measured analog
output level





(F)

68

Trim
analog
output gain

0

1

2…6

Analog output
number code
Analog output units
code
Externally
measured analog
output level





(F)

69

Write
analog
output
transfer
function

0

1

Analog output
number code
Analog output
transfer function
code

70

Read
analog
output
endpoint
values

0

Analog output
number code

0

1
2…5
6…9

Analog output number code
Analog output endpoint units code
Analog output upper endpoint value
Analog output lower endpoint value

107

Write Burst
mode
transmitter
variables
(for
command
33)

0

1

2

3

Transmitter variable
code for slot 0
Transmitter variable
code for slot 1
Transmitter variable
code for slot 2
Transmitter variable
code for slot 3

As

in

command
