User’s Manual Pub. 0300257-01 Rev. A

Appendix A
Module Specifications

General Specifications

Parameter 1734sc-IE4CH

Specification

1734sc-IE2CH

Specification

Module location

1734-TBxx

Pointbus current

15 mA

Power dissipation

0.6 W maximum @ 28.8V dc

Thermal dissipation

2.0 BTU/hr maximum @ 28.8V dc

Isolation Voltage

50V (continuous), Basic Insulation Type,

No isolation between channels

External DC power
Supply Voltage
Voltage Range
Supply Current

24V DC nominal

10..28.8V DC

20 mA @24V DC

24V DC nominal

10..28.8V DC

19 mA @24V DC

Dimensions (HxWxD), approx. 56 x 12 x 75.5 mm (2.21 x 0.47 x 2.97 in.)

Keyswitch position

3

Enclosure type rating

None (open-style)

Wire size

Determined by installed terminal block

Wiring category

2 – on signal ports

Wire type

Shielded

Terminal base screw torque

Determined by installed terminal block

Weight, approx.

35g (1.235 oz)

Input Specifications

Parameter 1734sc-IE4CH

Specification

1734sc-IE2CH

Specification

Number of Inputs

4 single ended, non-isolated

2 single ended, non-isolated

Resolution

16 bits

Input current terminal

4..20 mA limit: 3.42-20.58mA

Absolute accuracy

+/- 20 uA @ 25°C

Repeatability

+/- 5 uA @ 25°C

Accuracy drift w/temp.

50uA max -20..55°C, 30ppm / °C typical
