Point IO™ 2/4 Channel Analog HART Module

User’s Manual Pub. 0300257-01 Rev. A

Table B-3 (HART Universal Commands)

Command

Data in Command

Data in Reply

Contained in

No
.

Function

Byte

Data

Type

(1)

Byte

Data

Type

(1)

Input

Tag

CIP
MSG

0

Read
Unique
Identified

None

0

1
2
3
4
5
6
7
8
9…11

254 (expansion)
Manufacturer identification code
Manufacturer device type code Number of
preambles required Universal command
revision
Device-specific command revision
Software revision
Hardware revision

Device function flags

(2)

Device ID number









(H)
(B)

x

x
x
x
x
x
x
x
x
x

1

Read
primary
variable

0
1…4

PV units code Primary variable

(F)

x

x
x

2

Read
current and
percent of
range

None

0…3

4…7

Current (mA)
Primary variable %

(F)
(F)

x
x

x
x

3

Read
current and
four
(predefined)
dynamic
variables

None

0…3

4
5…8
9
10…13
14
15…18
19
20…23

Current (mA)
PV units code
Primary variable
SV units code
Secondary variable
TV units code
Third variable
FV units code

Fourth variable

(3)



x

x

x

x

x
x
x
x
x
x
x
x
x

6

Write
polling
address

0

Polling
address

As

in

command

11

Read unique
identifier
associated
with tag

0…5

Tag

(A)

0…11

As in command 0

12

Read
message

None

0…23

Message (32 characters)

(A)

x

13

Read tag,
descriptor,
date

0…5
6…17
18…20

Tag (8 characters)
Descriptor (16 characters)
Date

(A)
(A)
(D)

x

x
x

14

Read PV
sensor
information

0…2
3
4…7
8…11
12…15

Sensor serial number
Units code for sensor limits and min span
Upper sensor limit
Lower sensor limit
Min span

(B)

(F)
(F)
(F)

15

Read output
information

0
1
2
3…6
7…10
11…14
15
16

Alarm select code
Transfer function code
PV/range units code
Upper range value
Lower range value
Damping value (seconds)
Write-protect code
Private-label distributor code






(F)
(F)
(F)


x
x
x
x
x
x

16

Read final
assembly
number

None

0…2

Final assembly number

(B)

x

17

Write
message

0…23

Message
(32 characters)

(A)

As in command

18

Write tag,
descriptor,
date

0…5

6…17

18…20

Tag
(8 characters)
Descriptor
(16 characters)
Date

(A)

(A)

(D)

19

Write final
assembly

0…2

Final assembly
number

(B)
