Chapter 3: Configuring the 1734sc-IExCH for RSLogix 5000

3-13

User’s Manual Pub. 0300257-01 Rev. A

Alarm Disable

0: Process alarms enabled for associated channel.

1: Process alarms disabled for associated channel.

Enable HART Communication

0: Disable HART communication on associated channel.

1: Enable HART communication on associated channel.

3.5.2

Analog Notch Filter

The analog notch filter selection affects how the module attenuates the input signal at the
specified frequency. It also affects the update time of the input data which is reflected in
the minimum real time sample (RTS) rate that is available.

Table 3-3 (Analog Filter)

Notch Filter Selection 50/60Hz 50Hz 60Hz 100Hz 120Hz 240Hz 480Hz

Tag Value

1 2

3 4 5 6 7

Filter

Setting

96 96

80 48 40 20 10

Settling Time
(ms)

60 60

50 30 25

12.5

6.25

4 Channel
Sample Time
(RTS msec)

248 248

208 128 108 58 33

2 Channel
Sample Time
(RTS msec)

128 128

108

68 58 33 21

One setting applies to all channels in the module.

Value Units: NA

Value Limits: 1-7 (see Table 3-3 above)

3.5.3

RTS (Real Time Sample)

This parameter instructs the module how often to scan its input channels and obtain new
sampled data. After the channels are scanned, the module broadcasts that data over the
backplane.

Value Units: Milliseconds

Value Limits: 21-10,000 for IE2CH or 33 – 10,000 for IE4CH, actual minimum allowed
is based upon Module Filter selection Each module Filter selection will limit the
minimum value allowed, see Table 3-3.
