background image

Appendix A: IExCH Specifications

A-3

User’s Manual Pub. 0300257-01 Rev. A

Environmental Specifications

Environmental Tests

Industry Standards

Test Level Limits

Temperature (Operating)

(Performance Criteria A)

IEC60068-2-1: (Test Ad, Operating Cold),
IEC60068-2-2: (Test Bd, Operating Dry Heat),
IEC60068-2-14: (Test Nb, Operating Thermal Shock)

-20 to 55°C (-4 to 131°F)
(natural convection cooling)

Temperature
(Non-operating)

(Performance Criteria B)

IEC60068-2-1:
(Test Ab, Unpackaged Non-operating Cold),
IEC60068-2-2:
(Test Bb, Unpackaged Non-operating Dry Heat),
IEC60068-2-14:
(Test Na, Unpackaged Non-operating Thermal Shock)

-40 to 85°C (-40 to 185°F)

Humidity (Operating)

(Performance Criteria A)

IEC60068-2-30:
(Test Db, Unpackaged Damp Heat):

80 - 95% Condensing

20-60-20°C Temp Cycle

Vibration (Operating)

(Performance Criteria A)

IEC60068-2-6: (Test Fc, Operating)

10 to 500Hz, 5g

Shock (Operating)

(Performance Criteria A)

IEC60068-2-27: (Test Ea, Unpackaged Shock)

30 g,11ms half-sine (3 mutually
perpendicular axes)

Shock (Non-operating)

(Performance Criteria B)

IEC60068-2-27: (Test Ea, Unpackaged Shock)

50 g, 11ms half-sine (3 mutually

perpendicular axes)

Packaged Vibration

ES# PC003, Revision A

5 to 20 Hz 1 g. 1 hour each axis. 4

min sweep.

Packaged Shock
("drop test")

ES# PC004, Revision A

Drop from 48 in. 10 times each in

various orientations.

Radiated Emissions

CSIPR 11; Group 1, Class A

(Enclosure) Class A

Conducted Emissions

IEC 61000-6-4:2007

Group 1, Class A (AC Mains)

ESD immunity

(Performance Criteria B)

IEC 61000-4-2
Rockwell Document QTP#X0327

6kV Indirect (Coupling Plate)
6kV Contact Discharge ( to points of

initial contact)

8kV Air Discharge ( to points of

initial contact)

Radiated RF immunity
(Performance Criteria A)

IEC 61000-4-3: Level 3
Rockwell Document QTP#X0327

10 V/M with 1 kHz sine-wave

80%AM from 80…2000 MHz

10 V/M with 200 Hz sine-wave 50%

Pulse 100%AM @900 MHz

10 V/M with 200 Hz sine-wave 50%

Pulse 100%AM @1890 MHz

1 V/M with 1 kHz sine-wave

80%AM from 2000…2700 MHz

EFT/B immunity
(Performance Criteria B)

IEC 61000-4-4*
Rockwell Document QTP#X0327

± 3 kV @ 5 kHz for 5 minutes on

communication ports and power
ports

± 3 kV @ 5 kHz for 5 minutes on

(PE) ground port

Surge transient immunity
(Performance Criteria A)

IEC 61000-4-5
Rockwell Document QTP#X0327

±- 2 kV line-earth {CM}@ 2Ω on

communications ports

± 2kV CM @ 42Ω, ±1kV DM @

42Ω on unshielded ports

Conducted RF immunity
(Performance Criteria A)

IEC 61000-4-6
Rockwell Document QTP#X0327

10V rms with 1 kHx sine wave

80%AM from 150 kHz…80
MHz on communications, power
ports and (PE) ground

Magnetic Field

Not Applicable

AC Mains Voltage Dips,

Interruptions and
Variations

Not

Applicable

DC Mains Voltage Dips,

Interruptions and
Variations

Not

Applicable

Oscillatory Waves

Not Applicable

C-Tick (Australia)

AS/NZS CISPR 11 (Group 1, Class A)

Class A
