Appendix B: Additional HART Protocol Information

B-5

User’s Manual Pub. 0300257-01 Rev. A

Command

Data in Command

Data in Reply

Contained in

No
.

Function

Byte

Data

Type

(1)

Byte

Data

Type

(1)

Input

Tag

CIP
MSG

number

48

Read
additional
device
status

Starting

in

HART
version 7, the
data
in the command
could be the
same
as in the reply.

0…5

6…7
8
9
10
11
12
13
14…24

Device-specific status
Operational modes
Standardized status 0
Standardized status 1
Analog channel saturated
Standardized status 2
Standardized status 3

Analog channel fixed

(4)

Device-specific status

S

(5)

x

x
x
x
x
x
x
x
x

(1) (A) = Packed ASCII, (B) = 3-byte integer, (D) = Date, (F) = Floating Point (HART format), (H) = HART flag
(2) Bit 6 = multisensor device. Bit 1 = EEPROM control required. Bit 2 = protocol bridge device.
(3) Truncated after last supported variable.
(4) 24 bits each LSB…MSB refers to A0 #1…24.
(5) Sint []

Table B-4 (Common Practice Commands)

Command

Data in Command

Data in Reply

Contained in

No.

Function

Byte

Data

Type

(6)

Byte

Data

Type

(6)

Input

Tag

CIP
MSG

33

Read
transmitter
variables

None

0

1
2…5
6
7
8…11
12
13
14…17
18
19
20…23

Transmitter variable code, slot 0
Units code for slot 0
Variable for slot 0
Transmitter variable code, slot 1
Units code for slot 1
Variable for slot 1
Transmitter variable code, slot 2
Units code for slot 2
Variable for slot 2
Transmitter variable code, slot 3
Units code for slot 3

Variable for slot 3

(7)






(F)


(F)


(F)

34

Write
damping
value

0…3

Damping value
(seconds)

(F)

As in command

(F)

35

Write range
values

0
1…4
5…8

Range units code
Upper-range value
Lower-range value


(F)
(F)


(F)
(F)

36

Set upper-
range value
(= push
SPAN
button)

None

None

37

Set lower-
range value
(= push
ZERO
button)

38

Reset
‘configurati
on
changed’
flag

39

EEPROM
control

0

EEPROM control
code(3)

As

in

command

40

Enter/exit
Fixed
Current
mode

0…3

(1)

Current (mA)

(F)

As in command

41

Perform
device self-
test

None

None
