Chapter 4: IExCH and HART

4-11

User’s Manual Pub. 0300257-01 Rev. A

Table 4-13 (Reply Data)

HART Ladder Passthrough Init - Reply packet structure

Offset Field

Value

Definition

Unconnected Message Header
0

Status

32 = Busy (Queues full)
33 = DR_INITIATE
(passthrough success)
35 = DR_DEAD

Command Status
Note: HART Cmds
59,107,108, & 109 are not
allowed and will always
return DR_DEAD.

1 HART

Command

0-255 (1 byte)

Echo of HART command

2

Handle

1-255 (1 byte)

Handle used in Query
operation

3 Queue

Space

Remaining
OR
“Reason Code”
if status = 35

(1 byte)

Number of queues still
available for this channel.
OR
Reason Code is a diagnostic
value returned when message
fails(Status = 35)

Pass-through Query

The following table describes the class, service code and instances required to send the
Pass-through Query message.

Table 4-14 (Pass-through Query)

Unconnected Message

Field

Value

Definition

Message Type

“CIP Generic”

Service Code

0x4F

Passthrough Init

Class Name

0x035D

HART Object

Instance

1-4

Selects channel 0-3

Object Attribute None, leave this field blank
Request Size

1 byte

Handle for Query

Reply Size

6-260 bytes

Number of Data bytes returned

The following tables describe the possible message responses.

Table 4-15 (Request Data)

HART Ladder Passthrough Query - Request packet structure

Offset

Field

Value

Definition

0

Handle

1-255 (1 byte)

Handle for Query
