Point IO™ 2/4 Channel Analog HART Module

User’s Manual Pub. 0300257-01 Rev. A

Table 4-16 (Reply Data)

HART Ladder Passthrough Query - Reply packet structure

Offset Field

Value

Definition

0

Status

00 = Success
34 = DR_RUNNING
35 = DR_DEAD

Query Status

1

HART Command

0-255 (1 byte)

Echo of HART command

2

HART CommStatus

(1 byte)

HART Reply Status Byte #1

3 HART

FieldDeviceStatus

OR
Reason Code if status = 35

(1 byte)

HART Reply Status Byte #2

Reason Code is a diagnostic
value returned when message
fails(Status = 35)

4

Data Size

0-255 (1 byte)

Number of Data bytes in
reply for HART command

5-257

HART Reply Data …

Data bytes returned in data
field of HART reply to
requested command

HART Pass-through “Reason Code” definitions

The HART Pass-through “Reason Code” is a value that is reported when a Pass-through
reply message returns the general “Status” value as 35 (DR_DEAD). It provides the user
a diagnostic code, which is referenced in the table below, describing the possible cause of
the failure. This code will be returned in offset 3 of the reply message for Pass-through
Init or Query messages whenever the “Status” value at offset 0 is equal to 35
(DR_DEAD).

Table 4-17 (Reason Codes)

HART Pass-through Reason Code

Value Definition

Notes:

0x81

No response from HART device

0x82

Invalid long frame address

0x83

Invalid HART message checksum

0x84 HART Command not allowed

(blocked by module)

0x85

Invalid Channel selected

0x86

Channel is not HART Enabled

0x87

Channel does not have a device
connected

Module has not established HART
communications on this channel

0x89

Size of CIP message too small to
hold size of HART message

Module looks at HART Data size field in
request and validates that the incoming CIP
message size is large enough to send all the
data

0x8A

Invalid Handle

Only applies to a Query message

0x8B

Invalid Start Delimiter

Sending a Pass-through Message

The ladder on the following page demonstrates how to send a complete Pass-through
message using ladder. This example sends universal HART command 1 (Read Primary
Variable). For a listing of HART Universal and Common practice commands, see
Appendix B.
