Appendix B: Additional HART Protocol Information

B-7

User’s Manual Pub. 0300257-01 Rev. A

Command

Data in Command

Data in Reply

Contained in

No.

Function

Byte

Data

Type

(6)

Byte

Data

Type

(6)

Input

Tag

CIP
MSG

58

Write unit
tag,
descriptor,
date

0…5
6…17
18…20

Unit tag
Unit descriptor
Unit date

(A)
(A)
(D)

As in command

59

Write
number of
response
preambles

0

Number of response
preambles

60

Read
analog
output and
percent of
range

0

Analog output
number code

0

1
2…5
6…9

Analog output number code
Analog output units code
Analog output level
Analog output percent of range

61

Read
dynamic
variables
and
PV analog
output

None

0

1…4
5
6…9
10
11…14
15
16…19
20
21…24

PV analog output units code
PV analog output level
PV units code
Primary variable
SV units code
Secondary variable
TV units
Tertiary variable
FV units code
Fourth variable


(F)

(F)

(F)

(F)

(F)




x

x

x

x



x
x
x
x
x
x
x
x

62

Read
analog
outputs

0


1


2

3

(2)

Analog output
number;
code for slot 0
Analog output
number;
code for slot 1
Analog output
number;
code for slot 2
Analog output
number; code for

slot 3

(4)

0
1
2…5
6
7
8…11
12
13
14…17
18
19
20…23

Slot 0 analog output number code
Slot 0
Slot 0 level
Slot 1
Slot 1
Slot 1 level
Slot 2
Slot 2
Slot 2 level
Slot 3
Slot 3

Slot 3 level

(8)



(F)


(F)


(F)


(F)

63

Read
analog
output
information

0

Analog output
number code

0

1
2
3
4…7
8…11
12…15

Analog output number code
Analog output alarm select code
Analog output transfer function code
Analog output range units code
Analog output upper-range value
Analog output lower-range value
Analog output additional damping
value (seconds)





(F)
(F)
(F)

64

Write
analog
output

0

1…4

Analog output
number code
Analog output



(F)

As in command
