○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ ○ 4 Front/Rear Panel
Please insert the same drum kit instruments of the gk350 fro
C D E F G A B C D
5 5 5 5 5
1. POWER. Switch to turn the instrument ON and OFF.
2. VOLUME. Slider to control the instrument overall Volume.
3. CURSOR / PAGE. Navigation keys. The PAGE and PAGE keys select
the edit function pages. The CURSOR key is used to move among the
various sections of the page. The selected function is shown by a pointing
arrowhead in the display.
4. ARABIC SCALE. The control centre of all the Arabic Scale functions:
A
RABIC
S
CALE
: 12 buttons, arranged in keyboard octave style which lower
the corresponding notes of the keyboard by 1/4 of a tone in real time.
5. ARABIC SCALE MEMORY. This section contains 4 memory slots (1, 2, 3)
to select user-programmed Arabic scales, the S
TORE
button which memorizes
user-programmed Arabic notes and a general C ANCEL button to cancel the
current Arabic Scale selection.
6. MELODY OFF. This keys turns off the melody in the played back Song.
It is a useful feature when singing over the backing, or to play the melody
live on the keyboard.
7. DEMO. This key starts the Demo songs. The F1...F8 function keys select
the 8 Songs that demonstrate the instruments potential. F9 key plays the
Songs back in a sequence.
8. SINGLE TOUCH PLAY. When this function is active (the display indicates
it as ON), the sounds of a Style-Performance are assigned to the Style
tracks. The A
RRANGE ON
/
OFF
and A
RRANGE MEMORY
functions are
autmatically activated. In this mode, the 9 Function keys (F1 … F9)
recall 9 Single Touch Play settings that vary according to the selected Style.
When the display indicator is OFF when a Style is selected, only the sounds
from the Drum, Bass, Acc1,2,3 will change.
9. RECALL/STORE PERFORMANCE. Pressing this key puts you in Per-
formance mode, and the cursor arrowhead in the display moves down to
indicate PERF in the menu). The PAGE keys select the 7 groups that
contain the 63 Performances (each group features 9); (F1...F9) Function
keys recall the Performance. It is possible to modify the Performance settings
and save them. If the key is pressed and held for about 2 seconds, the
S
TORE P ERFORMANCE is activated, where the control panel settings may be
saved to the current Performance and even renamed it with a new Perfor-
mance name.
10. (F1 … F9) FUNCTION KEYS (S.T.PLAY/PERFORMANCE). These
keys select Demo Songs, Performances, Single Touch Play settings, Style,
Song Style or current Song tracks, depending on the selected mode of
WK1 Or. When in Song mode, the two rows of numbers under the function
keys correspond to the 16 Song Tracks (F1 … F8). F9 toggles between
tracks 01-08 and 09-16.
11. VARIATION 1, 2, 3, 4: These keys change the Style variation patterns
(the display indicator is ON). The selected variation is shown by the relative
led which turns on.
12. FILL A, FILL B/TAP,LOWER MEMORY; ARRANGE ON/OFF
F
ILL
A (Fills to previous Variation): this key plays a Fill pattern (display indicator
ON) and then goes back to the previous Variation.
F ILL B(Fills to next Variation): when this key is pressed while a Style is
played (the display indicator turns ON), the Fill pattern is recalled and it
passes on to the successive Variation.
T AP - Tapping on this key 3 or four times automatically sets the beat speed
and starts the Style in the desired Tempo.
1 1 1 1 1
2 2 2 2 2
29 29 29 29 29
30 30 30 30 30
31 31 31 31 31
L OWER M EMORY : notes in the Lower section of the keyboard
continue to sound (display indicator ON) or stop (indicator
OFF) after releasing the keys played in the Lower section of
the keyboard.
A
RRANGE
O
N
/O
FF
: enables (led ON) or disables (led OFF)
the automatic accompaniment of the Styles.
13. START/STOP, INTRO, ENDING, KEY START/CONTINUE.
S
TART /S TOP Starts and stops a Style. I NTRO places the
introduction of a Style on stand-by before the Style starts.
E
NDING
adds an Ending pattern to a Style before stopping it.
K EY S TART synchronizes the start of a Style with a note or
chord played in the lower keyboard area. C ONTINUE resumes
the current Song Style or Song from the point where it had
been stopped.
14. TEMPO/DATA, ENTER, ESCAPE. T EMPO /D ATA Keys
modify the Tempo in Styles, Song Styles or Songs. When a
mode is selected where values may be edited, the – and +
keys modify the value of the selected parameter. E
NTER
confirms selections or changes made. E SCAPE cancels the
input data or exits the edit page.
15. SUSTAIN: adds a sustain effect to the three keyboard
sections (Upper 1, 2 e Lower) independently by the
Damper Pedal.
16. REV/CHO. Enables (led ON) or disables (led OFF) THE
Digital Signal Processori.
17. HARMONY: enables or disables the melody harmonizer.
WK1Oriental Front Panel
