Available models, Iqs-605p-hs controller unit – EXFO IQS-600 Integrated Qualification System User Manual
Page 11
Introducing the IQS-600 Integrated Qualification System
Integrated Qualification System
3
Available Models
Available Models
Below are diagrams to locate the components on your controller and
expansion units.
IQS-605P-HS Controller Unit
The front of the IQS-605P-HS controller unit is where you perform basic
operations such as turning your unit on or off, consulting LED indicators,
and using data-related peripherals (for example: the USB ports).
Note: Some features, such as the touchscreen and selection dial, may not be
available depending on the version of the software you are using.
Module connector pins
On/Off
button
USB 2.0 ports (2)
Stylus
Hardware buttons and selection dial (see
Understanding the Hardware Buttons and
Selection Dial (IQS-605P-HS) on page 10)
DVD-RW drive
LED indicators (see Understanding the
Touchscreen
Return to Local button
