Working with CD Files
80 FastReporter
Changing CD Settings
Changing CD Settings
The pass/fail thresholds that you set for CD projects are displayed on the
Summary tab in the Results window. Should you need to change the
wavelength measurement range for analysis purposes, this is also done in
the Summary tab.
The dispersion thresholds are applied on the maximum dispersion for the
measurement file and on each dispersion value of the CD table.
To change CD options:
1. On the Project menu, select CD Properties.
2. Select the type of threshold to use for your analysis, either from the
measurement file itself or from a list of predetermined thresholds.
³
The threshold from the measurement file is the one that was used
during the actual CD test. When you select this threshold, you
cannot modify the values in the threshold table.
³
The threshold from the application is a threshold set by
FastReporter, which you can select and modify.
3. Modify the displayed values as needed. The Apply option must be
enabled for the values to be active and modifiable.
