Working with iOLM files
Data Post-Processing Software 135
Link View
³
Element Pass/Fail: The status of the element whether it is pass, fail, or
unknown.
³
Element Pass icon: The pass status of the element.
³
Element Fail icon: The fail status of the element.
³
Pass/Fail not tested: Gray background indicates that the element is
unknown. If there is no icon at the right side corner, it indicates that
thresholds are not applied on the element and the element is not
tested for Pass/Fail.
³
Diagnostics icon: This icon specifies that some diagnostics is
present on the element. See Diagnostics on page 141, for more details.
³
Distance Unit: The units are defined in the Distance unit under
General tab in User Preferences.
³
Splitter Ratio: The splitter ratio is displayed on the element, if the
element type is splitter.
Note: The number of elements displayed in the composition view varies
according to the a available space, number of elements, and section size.
Note: When the link length is large not all of the elements are visible; you may
need to scroll on the link using the navigation arrow.
Note: The distance between the elements are not 100% proportional. To have a
proportional representation of the element, see Link Overview on
page 133.
