EXFO FastReporter Data Post-Processing Software - Manual (Page 47)

Working with OTDR Files
Data Post-Processing Software 41
Changing OTDR Settings
To set macrobend tolerances:
1. On the Project menu, select OTDR Properties.
2. Click the Tolerances tab.
3. If needed, add a wavelength pair by clicking the button located at
the bottom of the Macrobend tolerances section, entering the
wavelength values, and clicking OK.
To remove one or more wavelengths, select the values in the
Wavelength list using the Ctrl or Shift keys as needed, and click the
button.
If you select more than one wavelength in the list, any modification to
the thresholds will apply to all of the selected wavelengths.
If needed, change the tolerance for the wavelength pair, by
clicking the corresponding tolerance value in the Tolerance
column, and enter the new value.
