EXFO FastReporter Data Post-Processing Software User Manual
Page 114
Working with FIP files
108
FastReporter
FIP Graphic Display Options
To change FIP graphic display options:
1. On the View menu, select FIP to display the FIP graphic display
options.
OR
On the graphic itself, click the right mouse button to display the FIP
graphic display options on the shortcut menu.
2. Select or clear Show Image option. The FIP image will be displayed
exactly next to the Overlay in the graphics window if the Show Image
option is activated.
