Otdr representation – EXFO FastReporter Data Post-Processing Software User Manual
Page 142
Working with iOLM files
136
FastReporter
Link View
OTDR Representation
The OTDR Representation option, displays the OTDR trace representation
of the Link View. You can activate OTDR representation display using
various ways.
To view the OTDR Representation from View menu:
1. Select an iOLM measurement from measurements window.
2. From the View menu, select iOLM, and View OTDR Representation.
