Working with FIP files
Data Post-Processing Software 107
FIP Graphic Display Options
FIP Graphic Display Options
Your FastReporter application displays the FIP overlay in the graphics
window along with the FIP Image. An Overlay highlights the
inconsistencies in your FIP with different colors described below.
³
FAIL Anomaly: the presence of this anomaly implies automatically a
FAIL result.
³
PASS Anomaly: the presence of this anomaly is not sufficient to confirm
a FAIL, the anomaly count in this case is relevant.
Image is available only when single FIP measurement is selected. When
multiple FIP measurements are selected, the window remains blank. Your
FastReporter application also allows copying the FIP Image and/or Overlay
and pasting it to the clipboard.
You can also change the display setting of graphics for FIP measurements.
Color Legend Analysis Anomaly Highlighting
Aqua PASS Scratch
Green PASS Defect
Red FAIL Anomaly
