TEST YOUR KNOWLEDGE #3
1. Adjusting the input to something based on what its output is doing is an example of __________.
2. A speaker converts electrical energy into __________ __________ variations, called sound waves.
3. An oscillator’s frequency __________ when you add resistance or capacitance.
4. A NOR gate followed by a NOT gate is the same as an __________ gate.
5. An AND gate followed by a NOT gate is the same as a __________ gate.
(Answers are on page 3)
TROUBLESHOOTING GUIDE
• Check your wiring against the Wiring Diagram and the schematic, very carefully. Be sure all your wires and components
are securely in place in the correct hole and not loose. Make sure the metal in the wires and components is not
contacting any other metal, since this will create “short circuits”. Nearly all problems are due to wiring errors.
• Remember that the battery and electrolytic capacitors have “+” and “–” terminal markings, and be sure to correctly
position the transistors, LEDs, diode, and transformer as per the guides.
• Be sure you have a good 9V battery. If not sure then try a new battery.
• Be sure you understand how to read the resistor color code, so that you use the right value parts.
• Be sure you understand which breadboard holes are connected to which.
Contact ELENCO ® (our address/phone/website is on the back of this booklet) if you further assistance. DO NOT contact
your place of purchase as they will not be able to help you.
