Elenco Basic Electronic Experiments - Manual (Page 3)

PARTS LIST
Quantity Part Number Description
r 1 134700 470Ω Resistor, 0.25W
r 1
141000 1k
Ω Resistor, 0.25W
r 1
143300 3.3k
Ω Resistor, 0.25W
r 1
151000 10k
Ω Resistor, 0.25W
r 1 153300 33k Ω Resistor, 0.25W
r 1 161000 100k Ω Resistor, 0.25W
r 1 171000 1M Ω Resistor, 0.25W
r 1
191549 50k
Ω Variable Resistor, lay-down, with dial
r 1
235018 0.005
μF Disc Capacitor
r 1
244780 0.047
μF Disc Capacitor
r 1
271045 10
μF Electrolytic Capacitor
r 1
281044 100
μF Electrolytic Capacitor
r 1 314148 Diode, 1N4148
r 3 323904 Transistor, NPN, 2N3904
r 2
350002 Light Emitting Diodes (LEDs)
r 1
442100 Transformer
r 1 540100 Switch, push-button
r 1
590098 9V Battery Clip
r 1
590102 Speaker, 8
Ω, 0.25 Watt, with wires added
r 1
- Wires Bag
QUIZ ANSWERS
First Quiz: 1. electrons; 2. short; 3. battery; 4. increase; 5. insulators, conductors; 6. decreases, increases; 7. decreases;
8. voltage; 9. alternating, direct; 10. increases, decreases.
Second Quiz: 1. reverse; 2. LEDs; 3. amplifier; 4. integrated; 5. saturated; 6. direct, alternating; 7. decreases, increases;
8. magnetic; 9. increases; 10. twice
Third Quiz: 1. feedback; 2. air, pressure; 3. decreases; 4. OR; 5. NAND
