Specifications - 232
JT100/JT100 All Terrain Operator’s Manual
CMW
©
JT Power Pipe
® U.S. Metric
Length (per SAE J2022), nominal 177 in 4.5 m
Tool joint diameter (per SAE J2022) 4.0 in 102 mm
Tubing diameter (per SAE J2022) 3.63 in 92 mm
Minimum bend radius 205 ft 63 m
Weight (per SAE J2022) 229 lb 104 kg
Weight, 12 drill pipe and box 3760 lb 1710 kg
All Terrain Pipe U.S. Metric
Length, without inner pipe (per SAE J2022) 169.5 in 4.3 m
Joint diameter (per SAE J2022) 4.5 in 114 mm
Tubing diameter (per SAE J2022) 3.63 in 92 mm
Minimum bend radius 205 ft 63 m
Weight, with inner pipe (per SAE J2022) 284 lb 130 kg
Weight, with pipe box and 12 drill pipe 4430 lb 2010 kg
