JT30 /JT30 All Terrain Operator’s Manual
Controls - 52
Information Center
CMW
2. Module button Use to see more specific
information about the
Information Center, ESID,
Main, or Pipeloader
controllers. Provides access to individual
components in the system.
3. No buz / Buz on button Toggles indicator (intermittent
buzzer) off or on for reminder
when key is on but engine is
not running. IMPORTANT: If the key is left on,
battery will discharge.
4. Pipe counter button Displays pipe count in lower
part of display to allow
operator to count pipe while
drilling and backreaming.
Push to show pipe count and
pipe control buttons.
Pipe counter only works when running
automated add pipe or remove pipe
cycles. If changing pipe manually,
counter will not increase or decrease.
Can display both positive and
negative counts. Operator can
manually increase, decrease, or reset
pipe count if desired.
5. F5 button Has no functionality at this
time.
6. Fluid usage button Displays an estimate of
drilling fluid used since last
reset. Operator can reset estimated amount.
Item Description Notes
