7 - 4 Rev C Dolphin® 9500 Series User’s Guide
Ping Utility Window
Config Tab
The Config tab provides a list of all APs and peer stations in range. Use the list to create and edit SSID profiles for APs that you
want the terminal to associate with.
Preferred Profiles The Preferred Profiles section displays a list of your preferred profiles, the profiles you create or add
from the list of Active SSIDs below. When applied, the 802.11b radio searches for the APs in the exact
order shown in the list of profiles. This section is blank after the initial installation and each hard reset.
This section remains blank if there no automatic association preference selected.
Field Description
IP Address Displays the current IP address. Enter another IP address to ping.
Size (Bytes) Displays the current data packet size in bytes; 32 is the default.
You can select up to 8192 from the drop-down list.
Timeout (ms) Displays the current timeout; 500 is the default.
Increase or decrease it by tapping the up and down arrow buttons.
Clear Tap this button to clear IP Address input and the ping statistics field.
Ping Tap this button to ping the IP address entered in the input field.
Ping Statistics This section lists the pinging IP address and the pinging results.
