17-54
Cisco ONS 15600 Procedure Guide, R8.0
Chapter 17 DLPs E100 to E199
DLP- E169 Initiate a Lockout on a Path Protection Path
Step 2
In the Protection Groups area, choose the protection group that contains the card you want to clear.
Step 3
In the Selected Group area, choose the card you want to clear.
Step 4
In the Inhibit Switching area, click Unlock.
Step 5
Click Yes in the confirmation dialog box.
The Lock On or Lock Out is cleared.
Step 6
Return to your originating procedure (NTP).
DLP-E169 Initiate a Lockout on a Path Protection Path
Step 1
In node view, click the Circuits > Circuits tabs.
Step 2
Click the path you want to switch and click Edit.
Step 3
In the Edit Circuit window, click the Path Protection Selectors tab.
Step 4
In the Switch State column, click the row for the path you want to switch and select
Lockout of Protection.
Note
Refer to the Cisco ONS 15600 Reference Manual for a description of protection switching and
switch state priorities.
Step 5
Click Apply.
Working traffic is prevented from switching to the protect path.To clear the Path Protection path Lock
Out, complete the
“DLP-E170 Clear a Switch or Lockout on a Path Protection Circuit” task on
Step 6
Return to your originating procedure (NTP).
Purpose
This task applies a lock out of protection to a path protection circuit so
that working traffic cannot switch to the protection path. Lockouts
prevent traffic from switching under any circumstance and have a higher
priority than Manual or Force switches.
Tools/Equipment
None
Prerequisite Procedures
DLP-E26 Log into CTC, page 16-33
Required/As Needed
As needed
Onsite/Remote
Onsite or remote
Security Level
Provisioning or higher
