DLP- E114 Provision Section DCC Terminations
DLP-E114 Provision Section DCC Terminations
Note
The SDCCs and LDCCs should not be provisioned between SONET (ANSI) and SDH (ETSI) nodes
using CTC or TL1 because they cannot operate between SONET and SDH nodes. These communication
channels should be provisioned on similar nodes, such as SONET-to-SONET or SDH-to-SDH. To
establish communication channels between SONET and SDH nodes, create a DCC tunnel. See the
“DLP-E105 Create a DCC Tunnel” task on page 17-5
to create a DCC tunnel.
Step 1
In node view, click the Provisioning > Comm Channels > SDCC tabs.
Step 2
In the SDCC Terminations area, click Create.
Step 3
In the Create SDCC Terminations dialog box, click the ports where you want to create the DCC
termination. To select more than one port, press the Shift key or the Ctrl key.
Note
SDCC refers to the Section DCC, which is used for ONS 15600 DCC terminations. You can
provision the SONET Line DCCs and SDCCs (when not used as a DCC termination by the
ONS 15600) as DCC tunnels. See the
“DLP-E105 Create a DCC Tunnel” task on page 17-5
. You
can provision SDCC and Line DCC on the same port but it is not recommend. SDCC and Line
DCC are only needed on the same port during a software upgrade if the software version does
not support SDCC. Provision Line DCC termination on the port that already has SDCC see
“DLP-E189 Provision Line DCC Terminations” task on page 17-70
. Delete SDCC provisioned
on that port, see
“DLP-E198 Delete a Section DCC Termination” task on page 17-76
OSPF on the Line DCC termination if not enabled see
Termination” task on page 17-75
Step 4
In the Port Admin State area, click Set to IS to put the port in service.
Step 5
Verify that the Disable OSPF on SDCC Link is unchecked.
Step 6
If the SDCC termination is to include a non-ONS node, check the Far End is Foreign check box. This
automatically sets the far-end node IP address to 0.0.0.0, which means that any address can be specified
by the far end. To change the default to a specific the IP address, see the
DCC Termination” task on page 17-75
Step 7
In the Layer 3 box, perform one of the following:
•
Check the IP box only—if the SDCC is between the ONS 15600 and another ONS node and only
ONS nodes reside on the network. The SDCC will use PPP (point-to-point protocol).
•
Check the IP and OSI boxes—if the SDCC is between the ONS 15600 and another ONS node and
third party NEs that use the Open System Interconnection (OSI) protocol stack are on the same
network. The SDCC will use PPP.
Purpose
This task creates SONET Section DCC terminations required for alarms,
administration data, signal control information, and messages.
Tools/Equipment
None
Prerequisite Procedures
DLP-E26 Log into CTC, page 16-33
Required/As Needed
As needed
Onsite/Remote
Onsite or remote
Security Level
Provisioning or higher
