PA-P55SP3AV User's Manual
I/O Port Connectors
Serial Port cable connectors,
C0M1 (upper), COM2 (lower)
Game port
cable connector
Parallel Port
cable connector
Floppy Disk Drive
cable connector
IDE Hard Disk Drive
cable connectors.
Primary (left),
Secondary (right)
When you connect a ribbon cable, you must orient the cable connector so
that the Pin 1 edge of the cable is at the Pin 1 end of the on-board connec­
tor. The Pin 1 edge of the ribbon cable is colored to indentify it.
Port & Controller Cables
The mainboard comes with the following cables. External ports attach to the
mainboard with ribbon cables that are attched to the port mounting bracket.
External ports:
• 2 serial ports with ribbon cables attached to one mounting bracket
• 1 parallel port
• 1 game port
Internal Controller Cables
• 1 IDE ribbon connector cable
• 1 floppy disk drive ribbon connector cable
4 - 1 2
