Feature Guide
• BIOS support for Power management, "Plug and Play" fea­
tures and Enhanced IDE, including support for up to four IDE
hard disks or other IDE devices and hard disks larger than
528MB, up to 8.4GB. Auto detection of installed ГОЕ hard disk
drives via BIOS Setup Utility.
• On-board "Multi-I/O' with: 2 serial ports - 16550 Fast UART
compatible - the second UART can support an IrDA-compat-
ible infrared port module via the 5-pin onboard connector, in­
stead of the COM2 port; 1 parallel port with EPP and ECP ca­
pabilities; one standard Game port; floppy disk drive controller
with 2.88MB support.
• On-board PCI Bus Master IDE controller with two connectors
supports four IDE devices in two channels, faster data trans­
fer rates and supports Enhanced IDE devices such as Tape
Backup and CD-ROM drives. The controller supports PIO
Modes 3 and 4 at a maximum transfer rate of ITMB/second
and Bus Master ГОЕ DMA Mode 2 at maximum ITMB/second.
• Optional IrDA-compatible infrared port module and external
PS/2 port/cable.
• On-board NCR SCSI BIOS firmware supports the optional PCI
SC-200 SCSI controller card.
Static Electricity Precautions
Under the right conditions, static electricity will build up. If you
touch the mainboard or other sensitive components, the buHd-up will
discharge into the components and circuitry. Computer components
are sensitive to damage from static electric discharge. They can be
damaged or destroyed if the discharge is powerful enough. Static
build-up is most likely to occur in dryer and cooler conditions, but
it is always important to be cautious.
1 - 5
