P/I-P55SP3AV User’s Manual
To protect the mainboard and other components against damage
from static electric discharge, you should follow some basic precau
tions whenever you handle them:
1. Use a grounding wrist strap. The strap will have an 'alligator'
'dip at the end of a shielded wire lead. Clip it to a grounded
object. Any static electricity will then harmlessly discharge
through the strap. Put on and connect the strap before you
handle the components.
2. Use an anti-static pad. Put any components on the pad when
ever you work on them outside the computer. If you don't have
a pad, put the components on the anti-static bag they came in.
Both the wrist strap and pad are inexpensive and are generally
available from computer supply companies.
Mainboard Layout
The diagram on the next page shows the location of important
components on the mainboard. There are other small diagrams later
in the manual that point out the location of the topic being explained.
1. Pentium in ZIP Socket?
2. L2 Cache module socket & chip sockets
3. External Feature connectors & Battery
4. ISA expansion slots
5. VGA Feature (L), AV689 Port Card (R) connectors
6. PCI expansion slots
7. I/O, Floppy & IDE connectors
8. SIMM memory banks
9. PS/2 Mouse connector (or port option)
10. Keyboard connector
11. Power Supply connector
1 - 6
