P/I-P55SP3AV User's Manual
Main Features
The P/I-P55SP3AV has many performance and system features
integrated onto the mainboard, including the following:
• Supports 75, 90,100,120,133,150 or 166MHz P54C/CS/CQS
Pentium CPUs in a ZIP (Zero Insertion Force) Socket 7.
• SIS 551X chipset
• Uses 72-pin SIMM DRAM modules of 1MB to 128MB in mul­
tiple configurations up to 512MB, with support for both Fast
Page Mode and Extended Data Output (EDO) SIMMs.
• Write-back "Level 2" external static RAM cache with two cache
options, SRAM DIP sockets and a cache module socket. Sock­
eted SRAM allows installation of 256KB, 512KB or 1MB of
Asynchronous 15ns SRAM.
With a cache module in the cache socket, the SRAM DIP sock­
ets are disabled. Cache module options include 256KB or
512KB Pipelined SRAM.
• On-board SIS 6205 Super VGA video display chip supports
mulitple resolutions and color depths using system DRAM.
• On-board ESS 1788 AudioDrive audio chip supports 16-bit
soimd card features.
• AV689 Audio/Display port card with audio jacks, volume con­
trol, Wave Table daughter-card connector and CD-ROM drive
audio connectors. Standard 15-pin VGA display card port.
• Four 16-bit ISA, three 32-bit PCI expansion slots, with one
shared PCI/ISA slot position. The PCI slots are Bus Master
capable. Additional connector for the AV689 Audio/Display
port card.
1-4
