Upgrade Guide

Module Sockets & Orientation

Cut-out

SIMMs have a cut-out at one end that matches an
extension on one of the vertical posts of each socket.

SIMM#

4 3

I

2

1

I

r? 1^

!'

1

1

■

t

rli

Put orientation cut-out at this end.

Remember: Modules must be installed in pairs, in sequence and

must meet all the required specifications and be the same speed,

2 - 9
