P/I-P55SP3AV User's Manual
Setting the INT Assignment
As explained in Chapter 2, any PCI card you install must use PCI
INT A. On the PCI-SC200, you assign the INT by setting jumper JPl
or JP2. The default setting for the card already is INT A, so you do
not need to change the setting to use the SC-200 with this mainboard.
The INT assignment jumper settings are illustrated below. The
settings are printed on the card for your convenience.
JPl & 2: Interrupt settings
CP
CM
»—
Q_ Q_
C)
CM
«—
O- Q_
o
CM
»—
O- O-
o n
o
6
o
“5
—>
1
o
O'
—> —i
o
C)
i)
(...)
—3
“3
CC)
s
INT A
(default)
INTB
INTO
CM
O-
INTD
Terminator Settings
SCSI devices are connected together in a "chain" by cables. In
ternal devices connect to the PCI-SC200 with a fifty-pin flat ribbon
cable. External devices connect to the external port with a SCSI-2
cable. If there is more than one internal or external device, additional
devices are connected with cables to form a "daisy chain". The SCSI
chain must be "terminated" at both ends, or the devices in the chain
will not work properly.
4 - 1 6
