1. The approximate operating weight of the unit is:
09DK-074— _________ 2200 ib [998 kg]
09DK-074-C----------------»2617 ib
[1187 kg]
09DK-084----------------- »• 2421 ib [1098 kg]
09DK-084--C--------------»-3099 Ib
[1406 kg]
2. Unit must have clearances for airflow as follows:
Top — Do nof restrict in any way.
Ends — 5 ft [1524 mm]
Sides — 6 ft [1829 mm]
3. All units are shipped with a capacity split tubing kit. This kit may be used by
the field to obtain 100%, 50%/50% and 67%/33% capacity splits. To obtain
a 33%/33%/33% capacity split, coils must be manifolded by fhe field. Coils
are factory circuited for a 33%/33%/17%/17% capacity split.
NOTES.
DIMENSION Y DIMENSION X
OPERATING CORNER WEIGHTS
A В C D
09DK-074—
3’-6 1/2"
[1080 mm]
4'-8 11/16"
[1440 mm] 618 Ib
[280 kg]
526 Ib
[239 kg]
486 Ib
[220 kg]
571 Ib
[259 kg]
09DK-074-C
3'-6 13/16"
[1087 mm] 4'-9 3/8"
[1458 mm]
722 Ib
[328 kg]
630 Ib
[286 kg]
589 Ib
[267 kg]
675 Ib
[306 kg]
09DK-084—
3'-6 5/8"
[1082 mm]
4'-9 1/8"
[1450 mm]
673 Ib
[305 kg]
581 Ib
[264 kg]
541 Ib
[245 kg]
6261b
[284 kg]
09DK-084-C
3'-7"
[1092 mm]
4'-10 1/8"
[1476 mm]
843 Ib
[382 kg]
751 Ib
[341 kg]
709 Ib
[322 kg]
796 Ib
[361 kg]
Ov
- ? ' - 4 11/16'- С22531ПЛ1
П6) MTG HOLES
17/32' DIA.—V
C13.5 bb 3
HINGED ACCESS
PANEL
(CONTROL BOX)
r-4 7/8'-
С42В.5в>т:
HT6. HOLES
Г-5 1/2'- C444m}
HTG. HOLES
Г-4 3/4'-
L425cnir>3
MTG. HOLES
-Г-5 1/2'
C444nti3
MTG. HOLES
»-1 1/2'
[Se.Snnl
MTG. HOLES
• 7/8'
[428.Siw]
MTG. HOLES
CAPACITY SPLIT
CONNECTIONS
TYPE N0.5 SIZE
100%
HOT GAS 1,3.5.7 1 3/8' I.D.
LIQUID 2.4.6,8 7/8 I.D.
50%/50%
HOT GAS 1.3 5,7 1 3/8' I.D.
LIQUID 2,4 6,8 7/8 I.D.
67%/33%
HOT GAS 1.3.S 7 1 3/8' I.D.
LIQUID 2.4,5 8 7/8 I.D.
33%/33%/33%
HOT GAS 1 7 3.5 1 3/8' I.D.
LIQUID 2 8 4,6 7/8 I.D.
33%/33%/17%/17%
HOT GAS 1 7 3 5 1 3/8' I.D.
LIQUID 2 8 4 5 7/8 I.D.
(4) RIG HOLES
2 5/8' DIA. СбТтт]
• 7'-4 1/2'
[224?готЗ
BASE O verall
base overall
Fig. 4 — Dimensions; 074 and 084 Units
